8 1/2 XHR S 5165 AU(24013) Size XHR Series High-RPM PDC Drill Bit for Soft Formations
8 1/2 XHR S 5165 AU(24013) Size XHR Series High-RPM PDC Drill Bit for Soft Formations
Basic Properties
Place of Origin:
CHINA
Brand Name:
XINGTONG
Certification:
API、ISO 9001
Model Number:
8 1/2 XHR S 5165 AU(24013)
Trading Properties
Minimum Order Quantity:
1 Picece(MOQ)
Price:
Negotiable
Payment Terms:
L/C,D/P,T/T,
Supply Ability:
Stable supply and support for bulk customization
Product Summary
8 1/2 XHR S 5165 AU(24013) Positioning The XHR series is a high-RPM drill bit engineered for high-speed drilling operations in soft formations. Designed to maximize rate of penetration (ROP) in soft geological conditions, this drill bit utilizes an advanced tooth geometry configuration and hydraulic ...
Product Custom Attributes
Highlight
PDC drill bit 8 1/2 inch
,PDC drill bit XHR S
,PDC drill bit 5165 AU
Cutter Grade:
GI
IADC Code:
S323
Body Type:
STEEL
Face:
45
Gauge:
30
Updrill:
5
Nozzle Type & Count:
M*5
Chip Removal Groove Area Ratio:
57.1%
API Connection:
4-1/2REG
Make-Up TQ:
17.0-26.4KN.m
Gauge Length:
66mm
Make-Up Length:
311mm
Approximate Shipping Weight:
45kg
Recommended Weight On Bit（Maximum Acceptable）:
14-16T（133T）
Total Flow Area:
485mm^2
Product Description
Detailed Specifications & Features
8 1/2 XHR S 5165 AU(24013)
Positioning
The XHR series is a high-RPM drill bit engineered for high-speed drilling operations in soft formations. Designed to maximize rate of penetration (ROP) in soft geological conditions, this drill bit utilizes an advanced tooth geometry configuration and hydraulic optimization to deliver superior rock breakage efficiency and rapid cuttings removal, significantly accelerating drilling speed.
Technical Highlights
- Optimized for high-speed drilling in soft formations
- Hybrid matrix cutting teeth with irregular geometry enhance rock-breaking efficiency while increasing cuttings transport velocity
- CFD-optimized nozzles and flow passages provide superior cuttings-carrying efficiency during high-speed operations
- High-strength steel body enables thinner cutter blade design, preventing interference at the rear of the blade during high mechanical drilling rates
Applicable Operating Conditions
Ideal for drilling intervals in soft to medium-hard formations where accelerated penetration is required. Specifically designed for applications aiming to achieve the highest possible mechanical drilling rate.
