8 1/2 XH S 7169 B(24055) Size PDC Drill Bit with GI Cutter Grade and Steel Body for Hard Formations
8 1/2 XH S 7169 B(24055) Size PDC Drill Bit with GI Cutter Grade and Steel Body for Hard Formations
Basic Properties
Place of Origin:
CHINA
Brand Name:
XINGTONG
Certification:
API、ISO 9001
Model Number:
8 1/2 XH S 7169 B(24055)
Trading Properties
Minimum Order Quantity:
1 Picece(MOQ)
Price:
Negotiable
Payment Terms:
L/C,D/P,T/T,
Supply Ability:
Stable supply and support for bulk customization
Product Summary
Xingtong Drill Bit 8 1/2 XH S 7169 B(24055) Product Positioning The XH series represents Xingtong's high-durability drill bit lineup engineered specifically for ultra-hard and highly abrasive formations. Designed with the core objectives of extending bit life and maintaining stable penetration rates...
Product Custom Attributes
Highlight
PDC drill bit 8 1/2 XH
,Xingtong drill bit S 7169 B
,PDC drill bit with warranty
Cutter Grade:
GI
IADC Code:
S432
Body Type:
STEEL
Face:
108
Gauge:
38
Updrill:
7
Nozzle Type & Count:
M*10
Chip Removal Groove Area Ratio:
50.8%
API Connection:
4-1/2REG
Make-Up TQ:
17.0-26.4KN.m
Gauge Length:
62mm
Make-Up Length:
297mm
Approximate Shipping Weight:
44kg
Recommended Weight On Bit (Maximum Acceptable):
14-16T(133T)
Total Flow Area:
577mm^2
Product Description
Detailed Specifications & Features
Xingtong Drill Bit 8 1/2 XH S 7169 B(24055)
Product Positioning
The XH series represents Xingtong's high-durability drill bit lineup engineered specifically for ultra-hard and highly abrasive formations. Designed with the core objectives of extending bit life and maintaining stable penetration rates, this series incorporates enhanced wear-resistant materials and optimized structural design to achieve longer single-bit run times, reduce make-up and break-out operations, and improve overall drilling efficiency in extremely challenging formations.
Technical Highlights
- Specifically engineered for hard formations to enhance drill bit life and penetration rate performance
- Optimized crown geometry ensures uniform load distribution, reduces stress on individual teeth, and minimizes core gouging risk
- High-performance imported PDC cutters selected for superior shoulder wear resistance and impact resistance, extending overall service life
- Unique rear-flute design enhances drill bit durability while maintaining cutting aggressiveness
Applicable Operating Conditions
Ideal for drilling operations in extremely hard and highly abrasive formations where extended tool life and higher penetration rates are critical requirements.
