16 Inch API 7-1 Standard Tricone Rock Drill Bits with 68 Cutter PDC Drilling Bits

16 Inch API 7-1 Standard Tricone Rock Drill Bits with 68 Cutter PDC Drilling Bits
Basic Properties
Place of Origin: CHINA
Brand Name: XINGTONG
Certification: API 、ISO 9001
Model Number: 16″ 406mm XHR 6163
Trading Properties
Minimum Order Quantity: 1 Piece（MOQ）
Price: Negotiable
Payment Terms: L/C,D/P,T/T,
Supply Ability: Stable supply and support for bulk customization.
Tags:

tricone bit
Product Summary
16 Inch Tricone Rock Drill Bits API 7-1 Steel Body PDC Drilling Bits 68 Cutter Mining Well PDC Drilling Bits 16 Inch API 7-1 Standard Factory Drill Bit Steel Body PDC Bits XHR Series Features Suitable for improving ROP in soft formation Optimize shaped cutter layout to improve the drilling ...
Product Custom Attributes
Highlight

16 Inch Tricone Rock Drill Bits

,

tri cone rock bit API

,

PDC Drilling Bits 68 Cutter

Cutter Type:
GII
IADC Code:
S123
Body Type:
STEEL
Total Cutter Count:
68
Face:
12+44
Gauge:
12
Updrill:
6
Nozzle Type & Count:
L*9
Junk Slot Area (sq Mm):
44554
Normalized Face Volume:
66.93%
API Connection:
6-5/8 REG.pin
Make-Up TQ:
50-59KN.m
Gauge Length:
89mm
Make-Up Length:
597mm
Approximate Shipping Weight:
418kg
Product Description
Detailed Specifications & Features
16 Inch Tricone Rock Drill Bits API 7-1 Steel Body PDC Drilling Bits 68 Cutter

Mining Well PDC Drilling Bits 16 Inch API 7-1 Standard Factory Drill Bit Steel Body PDC Bits

XHR Series Features
  • Suitable for improving ROP in soft formation
  • Optimize shaped cutter layout to improve the drilling efficiency and improve cuttings removing
  • Optimize nozzles and junk slot design by using CFD to speed up cutting moving
  • The high strength steel body makes the blade thinner to prevent back tail of the blade contact the formation while in high ROP
Product Features
  • Full Gauge
  • Smaller cone cutter
Important Notes
  • The recommended top-buckle torque is set according to the inner and outer diameter of the joint, with reference to API7G
  • The technical performance of the drill bits sold by Xingtong will be fully implemented in accordance with the terms agreed between Xingtong and the customer
  • The pictures are for reference only, please contact Skycom engineers for detailed technical parameters
