8 1/2 XHY 6163 A(24020) Size PDC Hybrid Drill Bit with Dual-Cone Cutters for Hard Formation Drilling
8 1/2 XHY 6163 A(24020) Size PDC Hybrid Drill Bit with Dual-Cone Cutters for Hard Formation Drilling
Basic Properties
Place of Origin:
CHINA
Brand Name:
XINGTONG
Certification:
API、ISO 9001
Model Number:
8 1/2 XHY 6163 A(24020)
Trading Properties
Minimum Order Quantity:
1 Picece(MOQ)
Price:
Negotiable
Payment Terms:
L/C,D/P,T/T,
Supply Ability:
Stable supply and support for bulk customization
Product Summary
Xingtong Drill Bit 8 1/2 XHY 6164 A(24020) Product Positioning The XHY series represents a hybrid drill bit that seamlessly combines the durability of roller-cone bits with the high-efficiency rock-breaking capability of PDC bits. In hard-formation drilling applications, this series achieves an ...
Product Custom Attributes
Highlight
PDC drill bit with warranty
,Xingtong PDC drill bit 8 1/2
,XHY 6164 A drill bit
Body Type:
STEEL
Cutter Grade:
GI
Roller Cone:
2
Face:
20
Gauge:
23
Updrill:
4
Nozzle Type&Count:
M*4、D*2
Chip Removal Groove Area Ratio:
64.5%
API Connection:
4-1/2REG
Make-Up TQ:
17.0-26.4KN.m
Gauge Length:
137mm
Make-Up Length:
361mm
Approximate Shipping Weight:
59kg
Recommended Weight On Bit (Maximum Acceptable):
14-16T(133T)
Total Flow Area:
478mm²
Product Description
Detailed Specifications & Features
Xingtong Drill Bit 8 1/2 XHY 6164 A(24020)
Product Positioning
The XHY series represents a hybrid drill bit that seamlessly combines the durability of roller-cone bits with the high-efficiency rock-breaking capability of PDC bits. In hard-formation drilling applications, this series achieves an optimal balance between directional control in high-strength formations and the need for rapid penetration rates.
This innovative design delivers outstanding performance in complex formations such as conglomerates, effectively addressing the limitations of pure PDC bits under specific operating conditions.
Technical Highlights
- Suitable for directional drilling in hard formations and for increasing penetration rates in challenging geological conditions
- Features a mainstream design with dual-cone cutters and four cutting wings, utilizing bearings and seals sourced from international suppliers to ensure industry-leading service life
- Optimized cone-to-PDC cutter height differential enables superior directional control and sidetracking performance in hard formations compared to conventional PDC bits
- PDC-impregnated cutter teeth enhance roller cone cutting performance, resulting in extended drill bit durability when drilling through conglomerate and ultra-hard, highly abrasive sandstone formations
Applicable Operating Conditions
Ideal for drilling operations in hard formations that require simultaneous consideration of durability and directional performance. Specifically designed for:
- Directional drilling in hard rock formations
- Accelerated penetration in highly abrasive formations
