6 XH S 5167 AK(24036) PDC Drill Bit with GI Cutter Grade and 3-1/2REG API Connection for Hard Formations
6 XH S 5167 AK(24036) PDC Drill Bit with GI Cutter Grade and 3-1/2REG API Connection for Hard Formations
Basic Properties
Place of Origin:
CHINA
Brand Name:
XINGTONG
Certification:
API、ISO 9001
Model Number:
6 XH S 5167 AK(24036)
Trading Properties
Minimum Order Quantity:
1 Picece(MOQ)
Price:
Negotiable
Payment Terms:
L/C,D/P,T/T,
Supply Ability:
Stable supply and support for bulk customization
Product Summary
Xingtong Drill Bit 6 XH S 5167 AK(24036) Product Positioning The XH series represents Xingtong's high-durability drill bit line specifically engineered for ultra-hard and highly abrasive formations. Designed with the core objectives of extending bit life and maintaining stable penetration rates, ...
Product Custom Attributes
Highlight
PDC drill bit 6 XH S 5167
,Xingtong PDC drill bit AK(24036)
,PDC drill bit with warranty
Cutter Grade:
GI
IADC Code:
S423
Body Type:
STEEL
Face:
25
Gauge:
24
Updrill:
5
Nozzle Type & Count:
M*5
Chip Removal Groove Area Ratio:
56.7%
API Connection:
3-1/2REG
Make-Up TQ:
7.1-11.5KN.m
Gauge Length:
60mm
Make-Up Length:
245mm
Approximate Shipping Weight:
20kg
Recommended Weight On Bit（Maximum Acceptable）:
10-12T （78T）
Total Flow Area:
289mm^2
Product Description
Detailed Specifications & Features
Xingtong Drill Bit 6 XH S 5167 AK(24036)
Product Positioning
The XH series represents Xingtong's high-durability drill bit line specifically engineered for ultra-hard and highly abrasive formations. Designed with the core objectives of extending bit life and maintaining stable penetration rates, this series incorporates enhanced wear-resistant materials and optimized structural design to deliver superior performance in demanding drilling conditions.
Technical Highlights
- Extended Service Life: Specifically designed for hard formations to enhance drill bit longevity and maintain optimal penetration rates
- Optimized Crown Geometry: Ensures uniform load distribution, reduces stress on individual teeth, and minimizes the risk of core removal
- Premium PDC Cutters: High-performance imported cutters enhance shoulder wear resistance and impact resistance for extended service life
- Advanced Flute Design: Unique rear-flute configuration enhances durability while maintaining cutting aggressiveness
Applicable Operating Conditions
Ideal for drilling operations in extremely hard and highly abrasive formations where extended tool life and consistent penetration rates are critical requirements.
