6 XH S 7139 A(24023) PDC Drill Bit with GI Cutter Grade 3-1/2REG API Connection and 65.4% Chip Removal Groove Area Ratio
6 XH S 7139 A(24023) PDC Drill Bit with GI Cutter Grade 3-1/2REG API Connection and 65.4% Chip Removal Groove Area Ratio
Basic Properties
Place of Origin:
CHINA
Brand Name:
XINGTONG
Certification:
API、ISO 9001
Model Number:
6 XH S 7139 A(24023)
Trading Properties
Minimum Order Quantity:
1 Picece(MOQ)
Price:
Negotiable
Payment Terms:
L/C,D/P,T/T,
Supply Ability:
Stable supply and support for bulk customization
Product Summary
Xingtong Drill Bit 6 XH S 7139 A(24023) Product Positioning The XH series represents Xingtong's high-durability drill bit lineup engineered specifically for ultra-hard and highly abrasive formations. Designed with the core objectives of extending bit life and maintaining stable penetration rates, ...
Product Custom Attributes
Highlight
PDC drill bit for hard rock
,Xingtong PDC drill bit 6 XH
,S 7139 A drill bit with warranty
Cutter Grade:
GI
IADC Code:
S432
Body Type:
STEEL
Face:
32
Gauge:
39
Updrill:
7
Nozzle Type & Count:
M*8
Chip Removal Groove Area Ratio:
65.4%
API Connection:
3-1/2REG
Make-Up TQ:
7.1-11.5KN.m
Gauge Length:
61mm
Make-Up Length:
244mm
Approximate Shipping Weight:
21kg
Recommended Weight On Bit（Maximum Acceptable）:
10-12T （78T）
Total Flow Area:
462mm^2
Product Description
Detailed Specifications & Features
Xingtong Drill Bit 6 XH S 7139 A(24023)
Product Positioning
The XH series represents Xingtong's high-durability drill bit lineup engineered specifically for ultra-hard and highly abrasive formations. Designed with the core objectives of extending bit life and maintaining stable penetration rates, this series incorporates enhanced wear-resistant materials and optimized structural design to deliver superior performance in demanding drilling conditions.
Technical Highlights
- Enhanced performance in hard formations to extend drill bit life and improve penetration rates
- Optimized crown geometry ensures uniform load distribution, reduces stress on individual teeth, and minimizes core gouging risk
- High-performance imported PDC cutters selected for superior shoulder wear resistance and impact resistance
- Unique rear-flute design maintains cutting aggressiveness while enhancing overall drill bit durability
Applicable Operating Conditions
Ideal for drilling operations in extremely hard and highly abrasive formations where extended tool life and higher penetration rates are critical requirements.
