6 XHR S 5168 B(24030) High-RPM PDC Drill Bit for Soft Formations with 36 Face Design

  • 6 XHR S 5168 B(24030) High-RPM PDC Drill Bit for Soft Formations with 36 Face Design
  • 6 XHR S 5168 B(24030) High-RPM PDC Drill Bit for Soft Formations with 36 Face Design
  • 6 XHR S 5168 B(24030) High-RPM PDC Drill Bit for Soft Formations with 36 Face Design
  • 6 XHR S 5168 B(24030) High-RPM PDC Drill Bit for Soft Formations with 36 Face Design
  • 6 XHR S 5168 B(24030) High-RPM PDC Drill Bit for Soft Formations with 36 Face Design
  • 6 XHR S 5168 B(24030) High-RPM PDC Drill Bit for Soft Formations with 36 Face Design
  • 6 XHR S 5168 B(24030) High-RPM PDC Drill Bit for Soft Formations with 36 Face Design
  • 6 XHR S 5168 B(24030) High-RPM PDC Drill Bit for Soft Formations with 36 Face Design
  • 6 XHR S 5168 B(24030) High-RPM PDC Drill Bit for Soft Formations with 36 Face Design
  • 6 XHR S 5168 B(24030) High-RPM PDC Drill Bit for Soft Formations with 36 Face Design
Place of Origin CHINA
Brand Name XINGTONG
Certification API、ISO 9001
Model Number 6 XHR S 5168 B(24030)
Document 6 XHR S 5138 B(24030).pdf
Minimum Order Quantity 1 Picece(MOQ)
Price Negotiable
Packaging Details Standard Exported Package
Delivery Time 15-45 Days
Payment Terms L/C,D/P,T/T,
Supply Ability Stable supply and support for bulk customization
Product Details
Cutter Grade GI IADC Code S433
Body Type STEEL Face 36
Gauge 15 Updrill 5
Nozzle Type & Count M*5 Chip Removal Groove Area Ratio 57.5%
API Connection 3-1/2REG Make-Up TQ 7.1-11.5KN.m
Gauge Length 50mm Approximate Shipping Weight 17kg
Recommended Weight On Bit（Maximum Acceptable） 10-12T （78T） Total Flow Area 485mm^2
Highlight

PDC drill bit with tungsten carbide

,

Xingtong PDC drill bit 6 XHR S

,

durable PDC drill bit 5168 B
Leave a Message
Product Description
Xingtong Drill Bit 6 XHR S 5168 B(24030)
Positioning

The XHR series is a high-RPM drill bit engineered for high-speed drilling operations in soft formations. Designed to maximize rate of penetration (ROP) in soft geological conditions, this drill bit utilizes advanced tooth geometry and hydraulic optimization to deliver superior rock breakage efficiency and rapid cuttings removal, resulting in significantly increased drilling speeds.

Technical Highlights
  • Specifically designed for high-speed drilling applications in soft formations
  • Hybrid matrix with optimized irregular cutting teeth configuration enhances rock-breaking efficiency while accelerating cuttings transport velocity
  • CFD-optimized nozzles and flow passages provide superior cuttings-carrying efficiency during high-speed drilling operations
  • High-strength steel body construction enables thinner cutter blade profiles, preventing interference at the blade rear during high mechanical drilling rates
Applicable Operating Conditions

Ideal for drilling intervals in soft to medium-hard formations where accelerated penetration rates are required. Specifically designed for applications targeting maximum achievable mechanical drilling rates.
