Xingtong Drill Bit 6 1/2 XD S 5166 DRS(24001)

  • Xingtong Drill Bit 6 1/2 XD S 5166 DRS(24001)
  • Xingtong Drill Bit 6 1/2 XD S 5166 DRS(24001)
  • Xingtong Drill Bit 6 1/2 XD S 5166 DRS(24001)
  • Xingtong Drill Bit 6 1/2 XD S 5166 DRS(24001)
  • Xingtong Drill Bit 6 1/2 XD S 5166 DRS(24001)
  • Xingtong Drill Bit 6 1/2 XD S 5166 DRS(24001)
  • Xingtong Drill Bit 6 1/2 XD S 5166 DRS(24001)
  • Xingtong Drill Bit 6 1/2 XD S 5166 DRS(24001)
  • Xingtong Drill Bit 6 1/2 XD S 5166 DRS(24001)
Place of Origin CHINA
Brand Name XINGTONG
Certification API、ISO 9001
Model Number 6 1/2 XD S 5166 DRS(24001)
Document 6 12 XD S 5166 DR(24001).pdf
Minimum Order Quantity 1 Picece(MOQ)
Price Negotiable
Packaging Details Standard Exported Package
Delivery Time 15-45 Days
Payment Terms L/C,D/A,D/P,T/T,Western Union
Supply Ability Stable supply and support for bulk customization
Product Details
Cutter Grade GI IADC Code S322
Body Type STEEL Face 27
Gauge 19 Updrill 5
Nozzle Type & Count M*5 Chip Removal Groove Area Ratio 59.2%
API Connection 3-1/2REG Make-Up TQ 7.1-11.5KN.m
Gauge Length 75mm Make-Up Length 187.3mm
Approximate Shipping Weight 18kg Recommended Weight On Bit（Maximum Acceptable） 10-12T （78T）
Total Flow Area 485mm^2
Highlight

PDC drill bit 6 1/2 size

,

Xingtong drill bit with warranty

,

XD S 5166 DRS drill bit
Leave a Message
Product Description

  • Positioning

    The XD series drill bits are directional drilling tools designed to meet the demands of various directional well types, including coalbed methane drainage directional wells and oil horizontal wells. Incorporating the latest drill-bit design concepts and undergoing specialized optimization in both structure and materials, the XD series delivers highly efficient rock-breaking performance even under complex wellbore trajectory conditions.


    Technical Highlights

    1. Suitable for use with a rotary steerable system to increase the build rate, or with a screw motor to enhance directional drilling efficiency.
    2. Ultra-short body design reduces the effective make-up length by 40% compared with conventional drill bits, significantly enhancing deviation-control capability.
    3. The unique detent-tooth design ensures excellent tool-face stability even under enhanced weight-on-bit during directional sliding.
    4. The maximum build rate when used with a bent sub is ≥30°/30 m, and the maximum build rate when used with a rotary steerable system is ≥15°/30 m.


    Applicable Operating Conditions

    The XD directional series is designed for critical drilling sections such as the build-up and horizontal sections of directional wells and can be used in conjunction with downhole screw motors and other directional tools. In applications such as coal mine gas drainage boreholes and highly challenging, long-reach wells, this drill bit series has consistently delivered outstanding performance, achieving single-trip penetration and rapid rate-of-penetration.
